3200 Series Parameters
The following tables contain generic parameters for the 3200 series of
instruments. The first number under each scan type is the preset value; the range
of numbers is the accessible range for each parameter.
Table 2-1 3200 Series Instrument Parameters
Parameter
ID
Access
ID
Positive ion mode Negative ion mode
Q1 Q3 MS/MS Q1 Q3 MS/MS
CUR CUR 10 10 10 10 10 10
10 to 50 10 to 50 10 to 50 10 to 50 10 to 50 10 to 50
CAD CAD 0 2 3 0 2 3
n/a 0 to 12 0 to 12 n/a 0 to 12 0 to 12
IS
(1)
IS 5000 5000 5000 –4200 –4200 –4200
0 to 5500 0 to
5500
0 to
5500
–4500 to
0
–4500 to
0
–4500 to
0
IS
(2)
IS 1000 1000 1000 –1000 –1000 –1000
0 to 5500 0 to
5500
0 to
5500
–4500 to
0
–4500 to
0
–4500 to
0
IS
(4)
IS 1500 1500 1500 –1500 –1500 –1500
0 to 2500 0 to
2500
0 to
2500
–2500 to
0
–2500 to
0
–2500 to
0
NC
(3)
NC 1 1 1 –1 –1 –1
0 to 5 0 to 5 0 to 5 –5 to 0 –5 to 0 –5 to 0
NC
(5)
NC 1 3 3 –3 –3 –3
0 to 5 0 to 5 0 to 5 –5 to 0 –5 to 0 –5 to 0
TEM
(1,3,4,5)
TEM 0 0 0 0 0 0
0 to 750 0 to 750 0 to 750 0 to 750 0 to 750 0 to 750
OR DP 20 20 20 –20 –20 –20
0 to 400 0 to 400 0 to 400 –400 to 0 –400 to 0 –400 to 0
Q0 EP 10 10 10 –10 –10 –10
(EP = –Q0) 1 to 12 1 to 12 1 to 12 –12 to –1 –12 to –1 –12 to –1
IQ1 IQ1 Q0 +(– 1) Q0 +(–
1)
Q0 +(– 1) Q0 + 1 Q0 + 1 Q0 + 1
(IQ1 = Q0 + offset) –2 to –1 –2 to –1 –2 to –1 1 to 2 1 to 2 1 to 2
(1)
TurboIonSpray
®
ion source
(2)
NanoSpray
®
ion source
(3)
DuoSpray™ ion source (1 =
TurboIonSpray ion source, 2 = Heated Nebulizer)
(4)
PhotoSpray
®
ion source
(5)
Heated
Nebulizer
(6)
1 = On, 0 = Off
