7 Technical data
Manufacturer
Address JOKAB SAFETY AB
Varlabergsvägen 11
S-434 91 Kungsbacka
Sweden
Power supply
Operating voltage 24 VDC +15 %, -25 %
Total current consumption 47 mA (57 mA with max information output)
Information output: Max 10 mA
Time delay t (in/out) t < 70 µs
Voltage supply at normal operation
(protection OK) and 24 VDC supply
voltage
Dynamic input: between 9 and 13 volt (RMS)
Dynamic output: between 9 and 13 volt (RMS)
Information output: ~ 23 VDC
General
Protection class IP65
Ambient temperature Storage: -30…+70°C
Operation: -10…+55°C
Humidity range 35 to 85 % (with no icing or condensation)
Housing material Polyamide PA66, Macromelt, polybutylenterephthalate PBT,
Polypropene PP, UL 94 V0
Connectors Smile 10EA Tina: 5-pole cable, 1 m (Smile 10EA Tina)
Smile 11x* Tina: M12 5-pole male
Smile 12x* Tina: M12 5-pole male, M12 5-pole female
* - x can be all models -EA, -EAR, -SA, -SAR
Size 84 x 40 x 52 (L x W x H) – see drawing
Weight ~ 65 g
Colour Yellow base, red or black button
Actuator force (E-stop button) 22 +/- 4N
Actuator travel ~ 4 mm to latch
Mechanical life > 50,000 operations
Impact resistance (half sinusoidal) Max. 150 m/s
2
, pulse width 11 ms, 3-axis
(as per EN IEC 60068-2-27)
Vibration resistance (half sinusoidal) Max. 50m/s
2
at 10 Hz, 10 cycles, 3-axis
(as per EN IEC 60068-2-6)
Safety / Harmonized Standards
Approved standards European Machinery Directive 2006/42/EC
EN ISO 12100-1:2003, EN ISO 12100-2:2003,
EN 60204-1:2007, EN 954-1:1996, EN ISO 13849-1:2008,
EN 62061:2005, IEC 60947-5-1:2003 + A1:2009
IEC/EN 61508-1…7 SIL3, PFHd: 4.66*10
-9
EN 62061 SIL3
EN ISO 13849-1 Performance level: Pl e, category 4
EN 954-1 Category 4
Certificates TÜV Nord
