Chapter 2 - Start-Up Instructions
IV A 2 - 18 DCS 500B / DCP 500B Operating Instructions
12522 = decrease so that motor voltage is 90 %.
Flux and thus the field current as well are reduced.
How to proceed:
1. decrease 12522 (in steps of 100 at a time)
2. press ACT, read off motor voltage
3. press PAR and correct 12522 if necessary (then continue with 2.)
Read out and note down value of:
11003 = ......... (will later be entered in 1015)
12522 = decrease so that motor voltage is 70%.
Flux and thus the field current as well are reduced.
Proceed as described in (1. / 2. / 3.) above!
Read out and note down value of:
11003 = ......... (will later be entered in 1014)
12522 = decrease so that motor voltage is 40%.
Flux and thus the field current as well are reduced.
Proceed as described in (1. / 2. / 3.) above!
Read out and note down value of:
11003 = ......... (will later be entered in 1013)
12522 = 4095
12516 = 0
Internal reference value equal to zero.
Switch OFF power, thus stopping the drive!
1002 = 12512
1004 = 0
1009 = 10%
1010 = - 99%
As-delivered values (default values) for all 4 parameters restored.
1015 = equal to the 1st value of 11003
1014 = equal to the 2nd value of 11003
1013 = equal to the 3rd value of 11003
Linearization function matched to field circuit.
501 = 90 % of the rated motor voltage.
1012 = 90 % of the value on the motor rating plate.
This measure serves to provide a greater safety margin for the motor voltage
during start-up.
