Device description Connections
Pin allocation Ethernet interface (RJ-45)
Pin assigned as data transmission
device (MDI)
assigned as network termina-
tion device (MDI-X)
1 Tx+ Rx+
2 Tx- Rx-
3 Rx+ Tx+
4 n.c. n.c.
5 n.c. n.c.
6 Rx- Tx-
7 n.c. n.c.
8 1
8 n.c. n.c.
4.7.2 SFP Interfaces (Fo1 - Fo2)
All SFP interfaces are designed according to Small Form-Factor Pluggable (INF-8074i).
SFP interface (Fo1 - Fo2)
Electrical specification IEEE 802.3
Protocol Fast Ethernet
Data rate 100 Mbps
Duplex Full duplex or half duplex (manual)
Plug type SFP (INF-8074i)
Optical SFPs
2 km (62.5/125 and 50/125 μm multi mode)
15 km (9/125 μm single mode)
40 km (9/125 μm single mode)
80 km (9/125 μm single mode)
Cable
Further types on request
Plug type Duplex LC (IEC 61754-20, TIA604-10-A)
Details on available SFPs can be found in Chapter 4.10.1, "Optical SFP Modules"
WARNING
Only transceivers up to laser class 1 according to EN 60825-1 are allowed to be used for the
SFP interfaces.
ADVICE
Any warranty claims can only extend to SFPs delivered by ABB.
4.7.3 DSL interfaces (X3 - X4)
The data transmission method SHDSL "Single-pair High-speed Digital Subscriber Line" has
been specified by the International Telecommunications Union (ITU recommendation G.991.2)
and represents a modern, high performance, comfortable and secure communication
method. SHDSL works with data rates from 192 kbps up to 5.696 Mbps on a copper pair in full
1KGT150966 V0001 31
