IEC 61850 or
function name
ANSI Function description Bay control
REC650 (A02)
SP16GAPC Generic communication function for single point indication 16 inputs 16
MVGAPC Generic communication function for measured values 24
BINSTATREP Logical signal status report 3
RANGE_XP Measured value expander block 66
LMBRFLO Fault locator 1
I103MEAS Measurands for IEC 60870-5-103 1
I103MEASUSR Measurands user defined signals for IEC 60870-5-103 3
I103AR Function status auto-recloser for IEC 60870-5-103 1
I103EF Function status earth-fault for IEC 60870-5-103 1
I103FLTPROT Function status fault protection for IEC 60870-5-103 1
I103IED IED status for IEC 60870-5-103 1
I103SUPERV Supervision status for IEC 60870-5-103 1
I103USRDEF Status for user defined signals for IEC 60870-5-103 20
L4UFCNT Event counter with limit supervision 30
TEILGAPC Running hour meter 6
Metering
PCFCNT Pulse-counter logic 16
ETPMMTR Function for energy calculation and demand handling 6
2.4 Communication
GUID-5F144B53-B9A7-4173-80CF-CD4C84579CB5 v15
IEC 61850 or
function name
ANSI Function description Bay control
REC650 (A02)
Station communication
LONSPA, SPA SPA communication protocol 1
ADE LON communciation protocol 1
HORZCOMM Network variables via LON 1
PROTOCOL Operation selection between SPA and IEC 60870-5-103 for SLM 1
RS485PROT Operation selection for RS485 1
RS485GEN RS485 1
DNPGEN DNP3.0 communication general protocol 1
CHSERRS485 DNP3.0 for EIA-485 communication protocol 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP communication protocol 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485 communication protocol 1
Table continues on next page
Section 2 1MRK 511 423-UEN A
Application
28 Bay control REC650 2.2 IEC
Application manual
