Presentation / operation
Page 1-18 ABB Control - AC 31
1SBC 260400 R1001-b 06.99
Products Description References
90 series binary remote
units
07 DI 92 Binary remote unit
with 32 binary inputs 24 V d.c.
24 V d.c. power supply
GJR 525 2400 R0101
07 DC 91 Binary remote unit
with 16 binary inputs, 8 transistor outputs and 8 configurable
inputs/outputs 24 V d.c. / 0,5 A
GJR 525 1400 R0202
07 DC 92 Binary remote unit
with 32 configurable inputs/outputs 24 V d.c. / 0,5 A
GJR 525 2200 R0101
90 series analog remote
units
07 AI 91 Analog remote unit
with 8 inputs configurable current / voltage, Pt 100, Pt 1000 or
thermocouple types J, K, S
resolution 12 bits
24 V d.c. power supply
GJR 525 1600 R0202
07 AC 91 Analog remote unit
with 16 inputs/outputs configurable current / voltage
resolution 8 / 12 bits
24 V d.c. power supply
GJR 525 2300 R1001
Remote units with
IP 67 protection
07 DI 93-I Binary remote unit with IP 67 protection
with 16 inputs 24 V d.c.
24 V d.c. power supply
GJV 307 5613 R0202
07 DO 93-I Binary remote unit with IP 67 protection
with 8 transistor outputs 24 V d.c. / 2 A
24 V d.c. power supply
GJV 307 5611 R0202
07 DK 93-I Binary remote unit with IP 67 protection
with 8 inputs 24 V d.c. and 4 transistor outputs 24 V d.c. / 2 A
24 V d.c. power supply
GJV 307 5623 R0202
Safety remote units only
used with 07 KT93-S
07 DI 90-S Safety remote unit with 8 binary inputs 24 V d.c.
24 V d.c. power supply
GJR 525 0900 R0202
07 DO 90-S Safety remote unit with 8 transistor outputs 24 V d.c. / 0,5 A
24 V d.c. power supply
GJR 525 0800 R0202
07 AI 90-S Safety remote unit with 4 analog inputs, resolution 12 bits, 4..20mA
24 V d.c. power supply
GJR 525 1100 R0202
Remote counter units
Remote high speed counter unit, max. 50 kHz
4 inputs A/A, B/B, C/C - 5.15 or 24 V d.c.
modes : incremental, A-B (32 bits), A+B (32 bits), 3 (16 bit) stand-alone
counters or 3 (16 bit) frequency meters
100 ms to 6536.5 s
validation, RESET, set, reference point
7 transistor (24 V d.c. / 0.5 A) outputs for local comparison
management between 2 instructions and the counter value.
ICSF 08 D1 24VDC 24 V d.c. power supply FPR 332 3101 R1012
ICSF 08 D1 120VAC 120 V a.c. power supply FPR 332 3101 R0014
ICSF 08 D1 230VAC 230 V a.c. power supply FPR 332 3101 R0016
