Presentation / operation
ABB Control - AC 31 Page 1-19
1SBC 260400 R1001-b 06.99
Products Description References
Displays
TC 50 Display with 2 lines of 20 characters, 7 operator keys,
5 customizable keys for parameter modifications or process control
IP 65 front
128 pages with 6 data/page insertion
128 help messages + 128 information messages
RS232 liaison through the serial ports of the central units
MODBUS protocol or AC 31 programming mode
24 V d.c. power supply
Delivered with connecting cable for 40 and 50 series central units
1SBP260150R1001
TCWIN
Programming software for TC 50 under Windows NT and 95.
Delivered with connecting cable for 40 and 50 series central units
1SBS260280R1001
TCAD Display connected to CS 31 bus
2 lines of 16 characters
1 buzzer and 1 programmable key
127 messages + 1 background message with 2 embedded
data / message
IP 65 front
24 V d.c. power supply
Delivered with programming software
FPR 320 3526 R1002
CS 31 bus accessories
NCB CS 31 bus amplifier for 500 m
max. 2 000 m with 3 amplifiers
24 V d.c. power supply
FPR 347 1200 R1002
NCBR CS 31 bus amplifier for 500 m
max. 2 000 m with 3 amplifiers
with redundancy in parallel, ring or star
24 V d.c. power supply
FPR 347 1300 R1002
Cables
07 SK 50 PC programming cable - 40 and 50 series central units
SUB D9 connector to PC
1SBN260200R1001
07 SK 51
40 and 50 series central units MODBUS /ASCII communication cable -
SUB D9 connector to PC
1SBN260201R1001
07 SK 52 40 and 50 series central units programming cable
with bare wires / terminal connection to central unit
1SBN260202R1001
07 SK 53
40 and 50 series central units MODBUS /ASCII communication cable,
with bare wires / terminal connection to central unit
1SBN260203R1001
07 SK 54 TC 50 cable - 40 and 50 series central units 1SBN260204R1001
07 SK 55 PC-TC 50 programming cable
SUB D9 connector to PC
1SBN260205R1001
07 SK 57 TC 50 cable - 30 and 90 series central units 1SBN260207R1001
