ABB AC 800M

CI852 and TP852 – FOUNDATION Fieldbus H1 Interface Appendix A Hardware Units
160 3BSE 027 941 R301
Status indicators Red LED for error
Green LED for run
Yellow LED for traffic
Connector Male 9-pin D-type connector.
Current consumption from
CEX-bus 24 V
140 mA typical (200 mA max.).
Power dissipation 3.4W typical
Protection Rating IP20 according to EN60529, IEC 529.
Weight 700 g (1.5 lb) (package CI852K01 with CI852 and
TP852)
Dimensions W 59 x H 185 x D 127.5 mm (W 2.9 x H 7.3 x D
5.0 in). See Mounting Dimensions for proper
Ventilation on page 90.
Table 42. CI852 Foundation Fieldbus Interface Specifications (Continued)
Item Description
