ABB AC 800M

CI853 and TP853 – RS232-C Interface Appendix A Hardware Units
164 3BSE 027 941 R301
Communication speed Selectable in steps from 75 to 115200 baud.
75, 110, 134.5, 150, 300, 600, 1200, 1800, 2000,
2400, 9600, 19200, 38400, 115200 baud.
This range of transmission rates may be
limited by the communication protocol used.
See the communication protocol
documentation.
Galvanic isolation Unisolated
Status indicators Running normally: Green. Exceptional fault: Red.
Four traffic indictors - Rx and Tx - controlled by
traffic pace: Flashing yellow.
Connector Two RJ45 connectors on TP853.
Current consumption
(from CEX-bus 24 V DC)
100 mA typical (150 mA max.)
Power Dissipation 2.4W typical
Protection Rating IP20 according to EN60529, IEC 529.
Weight 700 g (1.5 lb) (package CI853K01with CI853 and
TP853)
Dimensions W 59 x H 185 x D 127.5 mm
(W 2.9 x H 7.3 x D 5.0 in)
For further information see Mounting Dimensions
for proper Ventilation on page 90.
Table 44. CI853 – RS232-C Communication Interface Specifications (Continued)
Item Description
