ABB AC 800M

CI854 and TP854 – PROFIBUS DP-V1 Interface Appendix A Hardware Units
168 3BSE 027 941 R301
Connectors Two DB9, female on TP854.
Current consumption
(from CEX-bus 24 V DC)
190 mA typical (max. 240 mA).
Power dissipation 4.6W typical.
Capacity Max 32 loads.
Protection Rating IP20 according to EN60529,
IEC 529.
Weight 700 g (1.5 lb) (package CI854K01 with
CI854 and TP854).
Dimensions W 59 x H 185 x D 127.5 mm
(W 2.9 x H 7.3 x D 5.0 in)
Table 46. CI854 PROFIBUS DP-V1 Interface Specifications (Continued)
Item Value
