CI856 and TP856 – S100 I/O Interface Appendix A Hardware Units
176 3BSE 027 941 R301
Technical Data
Table 50. CI856 S100 I/O Interface Specifications
Item Value
Type S100 I/O Communication Interface
Galvanic isolation No
Status indicators Run normally green, FAIL exceptionally red,
the indicator TO are yellow flashing at S100
I/O access time-outs.
Connector 36 pin centerline miniature ribbon
connector, female
Current consumption
(from CEX-bus 24 V DC)
120 mA typical (200 mA max.)
Power dissipation 2.9W typical
Capacity Max 5 I/O racks with 20 I/O units each
Protection Rating IP20 according to EN60529, IEC 529
Weight 700 g
(1.5 lb) (package CI856K01 with
CI856 and TP856)
Dimensions W 59 x H 185 x D 127.5 mm
(W 2.9 x H 7.3 x D 5.0 in)
