CI857 and TP853 – INSUM Interface Appendix A Hardware Units
178 3BSE 027 941 R301
Indicators
7DEOH &,±,1680,QWHUIDFH/(',QGLFDWRUV
'HVLJQDWLRQ&RORU )XQFWLRQ
F(ault) /Red Unit error detected. Controlled by Control
Software. Set and cleared by the Hardware during
controller Reset.
R(un) /Green Operating. Controlled by the Control Software.
Cleared by the Hardware during controller Reset.
Tx1 /Yellow flashing A yellow LED indicating transmission from the
communication unit COM1 port.
Rx1 /Yellow flashing A yellow LED flashes when data is being received
from the COM1 port.
Tx2 OFF Not used.
Rx2 OFF Not used.
