CI857 and TP853 – INSUM Interface Appendix A Hardware Units
180 3BSE 027 941 R301
Technical Data
7DEOH  &,,1680,QWHUIDFH6SHFLILFDWLRQV
,WHP 9DOXH
Type Ethernet unit.
Protocol TCP/IP
Communication speed 10 Mbit/s (half duplex)
Status indicators Running normally: Green. Exceptional
fault: Red. Two traffic indictors - Tx1/Rx1 -
controlled by traffic pace: Flashing yellow.
Connector 2 RJ45 (only COM1 is used).
Current consumption
(from CEX-bus 24 V DC)
150 mA typical (200 mA max.).
Power dissipation 3.6W typical.
Protection Rating IP20 according to EN60529, IEC 529.
Weight 700 g (1.5 lb) (package CI857K01with
CI857 and TP853).
Dimensions W 59 x H 185 x D 127.5 mm
(W 2.9 x H 7.3 x D 5.0 in)
