ABB AC 800M

Appendix A Hardware Units Power Supply Units – Types SD821, SD822 and SD823
3BSE 027 941 R301 183
Figure 44. SD822 Connections for 5A Power Supply
44 mm
L+ L+ L– L–
NL
65 mm (2.6
in)
PE
OK
SD822
230
Mains Voltage
Selection Switch
(115 / 230)
110 mm (4.3 in)
103 mm (4.1 in)
97 mm (3.8 in)
125 mm
(4.9
in
)
(1.7 in)
