ABB AC 800M

Power Supply Units – Types SD821, SD822 and SD823 Appendix A Hardware Units
188 3BSE 027 941 R301
Table 55. PSU’s SD821, 822 and 823 – Mounting Dimensions
Parameter
SD821
Converter
SD822
Converter
SD823
Converter
Dimensions, Width
HxD = 125 x 110
mm (4.9” x 4.3”)
50 mm (2.0 in) 65 mm (2.6 in) 120 mm (4.7 in)
Mounting spacing
W mm
10 mm (0.4 in) 15 mm (0.6 in) 15 mm (0.6 in)
Mounting spacing
H mm
25 mm (1.0 in) 25 mm (1.0 in) 25 mm (1.0 in)
Weight (lbs) 600 g (1.3 lb) 700 g (1.5 lb) 1100 g (2.4 lb)
