TC562 Modem Unit – (Westermo MD-12DC) Appendix A Hardware Units
192 3BSE 027 941 R301
cable resistance and capacitance. ABB recommends a minimum cable gauge of
0.2mm
2
with a capacitance of 40-80pF/m within an industrial environment.
For an office environment, ABB recommends a minimum cable gauge of 0.14mm
2
,
and a capacitance of 40-100pF/m. Use a shielded cable in a heavy industrial
environment and an unshielded cable in an office environment. A shielded cable is
often given a higher capacitance and will therefore provide a higher data
transmission speed.
Technical Data
Table 58. TC562 – Technical Data
Type
TC562 – Short Distance Modem
Manufacturer – Westermo – MD-12DC
Transfer Asynchronous, full/half duplex/simplex
Power Supply 24 V DC (Min. 12 V DC – Max 36 V DC)
Power Consumption 3 W
Dimensions 55 x 100 x 128mm (2.2 x 3.9 x 5.0 in.)
Weight 400 g (0.9 lb)
Table 59. Transfer Distance (Cable 0.3 mm
2
/42 pF/m)
Meters (yd.) bit/s
1000 ( 1094) 19200
2500 ( 2734) 9600
5000 ( 5468) 4800
8000 ( 8749) 2400
12000 (13123) 1200
18000 (19685) 600
