Section 1 Introduction PM8xx/TP830 Processor Unit – General
3BSE 027 941 R301 31
Figure 3. Processor Unit Assembly – General View
(here shown with PM860/TP830)
Cover Release Scre
w
Cover
Assembly
CEX-bus
Socket
ModuleBus Socket
Fuses
CEX-bus/ModuleBu
s
Baseplate
TP830
Processor Unit
