Section 2 Installation Installation in Cabinets
3BSE 027 941 R301 89
Figure 25. Floor Mounted Cabinet (Horizontal Unit Arrangement)
Voting
Units
SS822
Breakers
Mains
SD822 Redundant
Power Supply Units
Redundant
Power
Supply Units
(Field
Equipment)
SD822
