E-Bypass Configurations for ACH550 Drives 21
Installation
380…480 Settings
380 - 480 Volt, Codes for Overload Trip Current DIP Switch
HP Identification Frame Size Switch Code
1/1.5 ACH550-xx-03A3-4 R1 A
2 ACH550-xx-04A1-4 R1 A
3 ACH550-xx-06A9-4 R1 A
5 ACH550-xx-08A8-4 R1 A
7.5 ACH550-xx-012A-4 R1 A
10 ACH550-xx-015A-4 R2 B
15 ACH550-xx-023A-4 R2 B
20 ACH550-xx-031A-4 R3 C
25 ACH550-xx-038A-4 R3 C
30 ACH550-xx-044A-4 R4 D
40 ACH550-xx-059A-4 R4 D
50 ACH550-xx-072A-4 R4 D
60 ACH550-xx-078A-4 R4 E
60 ACH550-xx-077A-4 R5 E
75 ACH550-xx-096A-4 R5 E
100 ACH550-xx-124A-4 R6 F
125 ACH550-xx-157A-4 R6 G
150 ACH550-xx-180A-4 R6 G
200 ACH550-xx-245A-4 R7 H
250 ACH550-xx-316A-4 R8 H
300 ACH550-xx-368A-4 R8 H
350 ACH550-xx-414A-4 R8 H
400 ACH550-xx-486A-4 R8 H
