AC fuses13Drive control panel1
Main contactor (Q2, option +F250)14Operating switch2
Power cable connection terminals of the
drive module behind the shroud
15Main switch handle3
Drive module16Gratings for cooling air in4
Additional I/O terminal block (option +L504)17Gratings for cooling air out5
Drive control unit18
Mounting plate, see section Mounting plate
– R6 to R9 (page 42)
6
Common mode filter (option +E208)19Lifting lugs7
du/dt filter (option +E205)20Cabinet door fan8
Motor cable connection terminals21Power and control cable entries9
Note: For drives with no du/dt filter (option
+E205), the motor cables are connected
to the drive module terminals.
￭ Mounting plate – R6 to R9
The components and terminals on the mounting plate of frames R6 to R9 are shown
below. The layout of frames R6 and R7 is similar.
42 Operation principle and hardware description
