88
Additional Instructions to Comply with EN61800-3,
First Environment, Restricted Distribution, and AS/
NZS 2064, 1997, Class A
Note! AS/NZS 2064, 1997, Class A is valid for types ACS143-xKx-3.
Always use optional RFI filter as specified in Table 8 and 9 and follow the
instructions in the filter package for all cable screen connections.
The filters with regular cable lengths are shown in Table 8 and the filters with
extra long cable lengths in Table 9.
The motor cable lengths have to be limited as specified in Table 8 and 9. At
the motor end, the cable screen must be earthed 360 degrees with an EMC
cable gland (e.g. Zemrex SCG screened cable glands).
Table 8 Maximum motor cable lengths with input filter ACS100/140-IFAB-1,
-IFCD-1, or ACS140-IFAB-3, -IFCD-3 and switching frequency 4 kHz, 8 kHz
or 16 kHz.
Converter type
ACS100/140-IFAB-1
4kHz 8kHz 16 kHz
ACS141-K18-1, -H18-1 30 m 20 m 10 m
ACS141-K25-1, -H25-1 30 m 20 m 10 m
ACS141-K37-1, -H37-1 30 m 20 m 10 m
ACS141-K75-1, -H75-1 30 m 20 m 10 m
ACS141-1K1-1, -1H1-1 30 m 20 m 10 m
ACS141-1K6-1, -1H6-1 30 m 20 m 10 m
Converter type
ACS100/140-IFCD-1
ACS141-2K1-1 30 m 20 m 10 m
ACS141-2K7-1 30 m 20 m 10 m
ACS141-4K1-1 30 m 20 m 10 m
Converter type ACS140-IFAB-3
ACS143-K75-3, -H75-3 30 m 20 m 10 m
ACS143-1K1-3, -1H1-3 30 m 20 m 10 m
ACS143-1K6-3, -1H6-3 30 m 20 m 10 m
ACS143-2K1-3, -2H1-3 30 m 20 m 10 m
Converter type ACS140-IFCD-3
ACS143-2K7-3 30 m 20 m 10 m
ACS143-4K1-3 30 m 20 m 10 m
