106 Technical data
IEC data
 Ratings
The IEC ratings for the ACS800-01 with 50 Hz and 60 Hz supplies are given below.
The symbols are described below the table.
ACS800-01
size
Nominal
ratings
No-
overload
use
Light-overload
use
Heavy-duty use Frame
size
Air flow Heat dis-
sipation
(1
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW
m
3
/h
W
Three-phase supply voltage 208 V, 220 V, 230 V or 240 V
-0001-2 5.1 6.5 1.1 4.7 0.75 3.4 0.55 R2 35 100
-0002-2 6.5 8.2 1.5 6.0 1.1 4.3 0.75 R2 35 100
-0003-2 8.5 10.8 1.5 7.7 1.5 5.7 1.1 R2 35 100
-0004-2 10.9 13.8 2.2 10.2 2.2 7.5 1.5 R2 35 120
-0005-2 13.9 17.6 3 12.7 3 9.3 2.2 R2 35 140
-0006-2 19 24 4 18 4 14 3 R3 69 160
-0009-2 25 32 5.5 24 5,5 19 4 R3 69 200
-0011-2 34 46 7.5 31 7.5 23 5.5 R3 69 250
-0016-2 4462114211327.5 R4103340
-0020-2 55 72 15 50 11 37 7.5 R4 103 440
-0025-2 72 86 18.5 69 18.5 49 11 R5 250 530
-0030-2 86 112 22 80 22 60 15 R5 250 610
-0040-2 103 138 30 94 22 69 18.5 R5 250 810
-0050-2 141 164 37 132 37 97 30 R6 405 1190
-0060-2 166 202 45 155 45 115 30 R6 405 1190
-0070-2 202 282 55 184 55 141 37 R6 405 1440
