External +24 V DC power supply for the RMIO board via terminal X34 169
16
External +24 V DC power supply
for the RMIO board via terminal
X34
What this chapter contains
This chapter describes how to connect an external +24 V DC power supply for the
RMIO board via terminal X34. For the current consumption of the RMIO board, see
chapter
Motor control and I/O board (RMIO) (page 85).
Note: External power is easier to supply to the RMIO board via terminal X23, see
chapter
Motor control and I/O board (RMIO) (page 85).
Parameter settings
In Standard Control Program, set parameter 16.09 CTRL BOARD SUPPLY to
EXTERNAL 24V if the RMIO board is powered from an external supply.
