ABB ACS880+N5350 - Page 30

Terminal Specications 4-53AXD50000011888
Catalog Number
ACS880-01-
Frame
Size
Tightening Torque
L1, L2, L3, T1/U, T2/V, T3/W R-, R+/UDC+, UDC
Ground
T (Wire Screw) T (Terminal Nut) T (Wire Screw) T (Terminal Nut) T
Ibf-ft M... N-M Ibf-ft M... N-M Ibf-ft M... N-M Ibf-ft M... N-M Ibf-ft
N-M
440…480V
11A0-5+N5350 R1 0.4 0.6 0.4 0.6 1.3 1.8
014A-5+N5350 R2 0.4 0.6 0.4 0.6 1.3 1.8
021A-5+N5350 R2 0.4 0.6 0.4 0.6 1.3 1.8
027A-5+N5350 R3 1.3 1.7 1.3 1.7 1.3 1.8
034A-5+N5350 R3 1.3 1.7 1.3 1.7 1.3 1.8
040A-5+N5350 R4 2.4 3.3 2.4 3.3 2.1 2.9
052A-5+N5350 R4 2.4 3.3 2.4 3.3 2.1 2.9
065A-5+N5350 R5 11.0 15 11.0 15 2.1 2.9
077A-5+N5350 R5 11.0 15 11.0 15 2.1 2.9
096A-5+N5350 R6 22.1 M10 30 M8 24 14.8 M8 20 M8 20 7.2 9.8
124A-5+N5350 R6 22.1 M10 30 M8 24 14.8 M8 20 M8 20 7.2 9.8
156A-5+N5350 R7
29.5
(22.1*)
M10
40
(30*)
M8 24 14.8 M10 30 M10 30 7.2 9.8
180A-5+N5350 R7
29.5
(22.1*)
M10
40
(30*)
M8 24 14.8 M10 30 M10 30 7.2 9.8
240A-5+N5350 R8 29.5 M10 40 17.7 M10 24 29.5 M10 40 17.7 M8 24 7.2 9.8
302A-5+N5350 R9 51.6 M12 70 17.7 M10 24 51.6 M12 70 17.7 M8 24 7.2 9.8
361A-5+N5350 R9 51.6 M12 70 17.7 M10 24 51.6 M12 70 17.7 M8 24 7.2 9.8
414A-5+N5350 R9 51.6 M12 70 17.7 M10 24 51.6 M12 70 17.7 M8 24 7.2 9.8
660…690V
07A3-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
09A8-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
14A2-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
018A-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
022A-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
026A-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
035A-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
042A-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
049A-7+N5350 R5 11.0 15 11.0 15 2.1 2.9
061A-7+N5350 R6 22.1 M10 30 M8 24 14.8 M8 20 M8 20 7.2 9.8
084A-7+N5350 R6 22.1 M10 30 M8 24 14.8 M8 20 M8 20 7.2 9.8
098A-7+N5350 R7
29.5
(22.1*)
M10
40
(30*)
M8 24 14.8 M10 30 M10 30 7.2 9.8
119A-7+N5350 R7
29.5
(22.1*)
M10
40
(30*)
M8 24 14.8 M10 30 M10 30 7.2 9.8
142A-7+N5350 R8 29.5 M10 40 17.7 M10 24 29.5 M10 40 17.7 M8 24 7.2 9.8
174A-7+N5350 R8 29.5 M10 40 17.7 M10 24 29.5 M10 40 17.7 M8 24 7.2 9.8
210A-7+N5350 R9 51.6 M12 70 17.7 M10 24 51.6 M12 70 17.7 M8 24 7.2 9.8
271A-7+N5350 R9 51.6 M12 70 17.7 M10 24 51.6 M12 70 17.7 M8 24 7.2 9.8
* For 660…690V volt drives.
Table 4-2 Power Tightening Torque Specifications (Cont.)
