ABB ACS880+N5350 - 5.4 Wire Sizing and Fuses

Power Wiring 5-33AXD50000011888
5.4 Wire Sizing and Fuses
It is the responsibility of the installer to ensure that the ACS880+N5350 is installed in accordance with local electrical codes.
This includes, but is not limited to a proper disconnect, branch circuit protection, and wire size.
The following tables can be used as a guide to select wire gauge and input fuses. Recommendations are based upon the
maximum continuous current of the control. This table assumes 75°C wire.
Table 5-2 Wire Sizing
Control Rating
Wire Gauge
(AWG)
Catalog Number Frame kW HP Input Amps
ACS880-01-24A3-2+N5350
R2
5.5 7.5 24.3
10
ACS880-01-031A-2+N5350
R3
7.5 10 31
8
ACS880-01-046A-2+N5350
R4
11 15 46
6
ACS880-01-061A-2+N5350
R4
15 20 61
4
ACS880-01-075A-2+N5350
R5
18.5 25 75
3
ACS880-01-087A-2+N5350
R5
22 30 87
3
ACS880-01-115A-2+N5350
R6
30 40 115
1
ACS880-01-145A-2+N5350
R6
37 50 145
2/0
ACS880-01-170A-2+N5350
R7
45 60 170
3/0
ACS880-01-206A-2+N5350
R7
55 75 206
250 MCM
ACS880-01-274A-2+N5350
R8
75 100 274
-
ACS880-01-12A6-3+N5350 R1 5.5 7.5 12.6
14
ACS880-01-017A-3+N5350 R2 7.5 10 17
10
ACS880-01-025A-3+N5350 R2 11 15 25
10
ACS880-01-032A-3+N5350 R3 15 20 32
8
ACS880-01-038A-3+N5350 R3 18.5 25 38
8
ACS880-01-045A-3+N5350 R4 22 30 45
6
ACS880-01-061A-3+N5350 R4 30 40 61
4
ACS880-01-072A-3+N5350 R5 37 50 72
3
ACS880-01-087A-3+N5350 R5 45 60 87
3
ACS880-01-105A-3+N5350 R6 55 75 105
1
ACS880-01-145A-3+N5350 R6 75 100 145
2/0
ACS880-01-169A-3+N5350 R7 90 125 169
3/0
ACS880-01-206A-3+N5350 R7 110 150 206
250 MCM
ACS880-01-246A-3+N5350 R8 132 200 246
300 MCM
ACS880-01-293A-3+N5350 R8 160 225 293
2 x 3/0
ACS880-01-363A-3+N5350 R9 200 275 363
2 x 4/0
ACS880-01-430A-3+N5350 R9 200 350 430
2 x 250 MCM
