12.2 Level 1 Parameters (Advanced Prog, Level 1 Blocks)
Table 12-4 Level 1 Parameter Block Definitions
Block Title
Parameter (Number)
Selection (Value)
Descriptions
ACTUAL VALUES Basic signals for monitoring the drive. All parameters in this group are read-only unless otherwise noted.
MOTOR SPEED USED (01.01) Default: Read Only
Range: -30000.00 to +30000.00 RPM
Measured or estimated motor speed depending on which type of
feedback is used (see parameter 90.41 Motor feedback selection). A
lter time constant for this signal can be dened by parameter 46.11
Filter time motor speed.
MOTOR SPEED ESTIMATED
(01.02)
Default: Read Only
Range: -30000.00 to +30000.00 RPM
Estimated motor speed in rpm. a lter time constant for this signal can
be dened b parameter 46.11 Filter time motor speed.
MOTOR SPEED % (01.03) Default: 10 = 1%
Range: -1000.00 to +1000.00%
Measured or estimated motor speed. Shows the value of 01.01 Motor
speed used in percent of the synchronous speed of the motor.
OUTPUT FREQUENCY (01.06) Default: Read Only
Range: -500.00 to +500.00 Hz
Estimated drive output frequency in Hz. A lter time constant for this
signal can be dened by parameter 46.12 Filter time output frequency.
MOTOR CURRENT (01.07) Default: Read Only
Range: 0.00 to 30000.00 A
Measured (absolute) motor current in A.
MOTOR CURRENT % OF
MOTOR NOM (01.08)
Default: Read Only
Range: 0.00 to 1000.0 %
Measured motor current in %
MOTOR TORQUE % (01.10) Default: Read Only
Range: -1600.0 to +1600.0 %
Motor torque in percent of the nominal motor torque. See also
parameter 01.30 Nominal torque scale.
A lter time constant for this signal can be dened by parameter 46.13
Filter time motor torque
DC VOLTAGE (01.11) Default: Read Only
Range: 0.00 - 2000.00 V
Measured DC link voltage.
OUTPUT VOLTAGE (01.13) Default: Read Only
Range: 0 - 2000 V
Calculated motor voltage in VAC.
Fieldbus Equivalent: 10 = 1 V
OUTPUT POWER (01.14) Default: Read Only
Range: -32768 to +32767 kW or HP
Drive output power. The unit is selected by parameter 96.16 Unit
selection. A lter time constant for this signal can be dened by
parameter 46.14 Filter time power out.
OUTPUT POWER % OF
MOTOR NOM (01.15)
Default: Read Only
Range: -300.00 + 300.0%
Shows the value of 01.14 Output power in percent of the normal
power of the motor.
