ABB ACS880+N5350 - Page 38

Power Wiring 5-53AXD50000011888
The table below assumes 150% rated fast acting fuses.
Table 5-3 Fuses
Catalog Number Frame
Input
Current
Amps
Fuse (one fuse per phase)
A V Manufacturer Type UL Class
ACS880-01-24A3-2+N5350
R2
24.3
40
600
Bussmann JJS-40 T
ACS880-01-031A-2+N5350
R3
31
50
600
Bussmann JJS-50 T
ACS880-01-046A-2+N5350
R4
46
80
600
Bussmann JJS-80 T
ACS880-01-061A-2+N5350
R4
61
100
600
Bussmann JJS-100 T
ACS880-01-075A-2+N5350
R5
75
125
600
Bussmann JJS-125 T
ACS880-01-087A-2+N5350
R5
87
125
600
Bussmann JJS-125 T
ACS880-01-115A-2+N5350
R6
115
150
600
Bussmann JJS-150 T
ACS880-01-145A-2+N5350
R6
145
200
600
Bussmann JJS-200 T
ACS880-01-170A-2+N5350
R7
170
250
600
Bussmann JJS-250 T
ACS880-01-206A-2+N5350
R7
206
300
600
Bussmann JJS-300 T
ACS880-01-274A-2+N5350
R8
274
400
600
Bussmann JJS-400 T
ACS880-01-11A0-5+N5350
R1
11
20
600
Bussmann JJS-20 T
ACS880-01-014A-5+N5350
R2
14
25
600
Bussmann JJS-25 T
ACS880-01-021A-5+N5350
R2
21
35
600
Bussmann JJS-35 T
ACS880-01-027A-5+N5350
R3
27
40
600
Bussmann JJS-40 T
ACS880-01-034A-5+N5350
R3
34
50
600
Bussmann JJS-50 T
ACS880-01-040A-5+N5350
R4
40
60
600
Bussmann JJS-60 T
ACS880-01-052A-5+N5350
R4
52
80
600
Bussmann JJS-80 T
ACS880-01-065A-5+N5350
R5
65
90
600
Bussmann JJS-90 T
ACS880-01-077A-5+N5350
R5
77
110
600
Bussmann JJS-110 T
ACS880-01-096A-5+N5350
R6
96
150
600
Bussmann JJS-150 T
ACS880-01-124A-5+N5350 R6 124 200 600
Bussmann JJS-200 T
ACS880-01-156A-5+N5350
R7
156
225
600
Bussmann JJS-225 T
ACS880-01-180A-5+N5350
R7
180
300
600
Bussmann JJS-300 T
ACS880-01-240A-5+N5350 R8 240
350
600
Bussmann JJS-350 T
ACS880-01-260A-5+N5350 R8 260
400
600
Bussmann JJS-400 T
ACS880-01-302A-5+N5350 R9
302 400 600
Bussmann JJS-400 T
ACS880-01-361A-5+N5350 R9 361
500
600
Bussmann JJS-500 T
ACS880-01-414A-5+N5350 R9 414
600
600
Bussmann JJS-600 T
Note: For -3 and -7 drives, consult 3AUA0000078093 Hardware Manual for fuse information.
