ABB Adam DYN-Info M12-5 User Manual

2TLC172271M0201 Rev.H 29
11 Technical data
Manufacturer
Address ABB Electrification Sweden AB
SE-721 61 Västerås
Sweden
Power supply
Rated operating voltage
+24 VDC +15 % -40 %
Use SELV/PELV
Current consumption
30 mA at 24 VDC
35 mA at 18 VDC
(45 mA at 12 VDC)
Reset indication lamp output 30 mA max on pin 5 (Adam DYN-Reset)
Information output 15 mA max on pin 5 (Adam DYN-Info)
Electrical data
Voltage drop (DYNlink out) 2.5V@25mA
OFF-state current (DYNlink out) <3
µ
A
Transponder frequency 4 MHz
Max. switching frequency 1 Hz
Environmental data
EMC EN 60947-5-3:2013
Ambient temperature Operation: -40…+70 °C
Storage: -40…+70 °C
Humidity range Eden: 35 to 85 % (with no icing or condensation)
Eden C: 35 to 95 %
Times
Switch-on delay power on
2 s
Response time at activation <100 ms
Response time at deactivation <30 ms
Risk time <30 ms
Useful lifetime / mission time 20 years
Time delay between DYNlink input and
output signal (T
DELAY
)
Maximum: 60
µ
s
Mechanical data
Protection class
IP67/IP69K
Enclosure Type Rating:
Type 1
Material
Housing: Polybutylene terephthalate (PBT)
Molding: Epoxy
Connector
M12 5-pole male
Torque: 0.6 Nm
Mounting Screw torque: 1.0 Nm
Weight
Adam: 80 g
Eva: 70 g
Color
Yellow, grey text
Assured release distance (S
ar
)
25 mm
Assured operating distance (S
ao
)
10 mm
Rated operating distance (S
n
)
15 +/- 2 mm
Hysteresis
1-2 mm
