LOWER DISPLAY
Range 3
Operating Page
Lower Display
English
SECURITY CODE
SET UP OUTPUTS
Set Up Outputs Page
Electrical
Calibration Page
Access to
Secure Parameters
Language Page
No
Yes
Adjust RTX Zero
Adjust RTX Span
Calibrate No
ELECTRICAL CAL
Secure Parameters
Note. All parameter values shown on the upper
display line are the default settings.
RTX Type 4-20
0-20
0-10
AIR IN *
Alarm H2 IN *
Alarm Setpoint
Yes
NOT IN USE
Upper Display
EB
**
** Only when 'AIR IN *'
selected in Set Up Outputs page
Relay Action EA
Test Retrans (%)
mV Zero (0.00mV)
xxx.x
xxx.x
mV Span
Alter Sec. Code
%AIR IN *
SPT. AIR IN *
xxx.x
xxx.x
see Note
Note.
CO
2 – 10.00mV.
N
2 – 1.00mV.
Argon – 10.00mV.
10 PROGRAMMING...
Fig. 10.3 Overall Programming Chart for 6553 Display Unit (Range 3) – AK101 only
*Note. Purge gas options include:
CO
2
(Carbon dioxide)
N
2
(Nitrogen)
Ar (Argon)
