Typical Position of Plates - 89
3BFP 000 063 R0101 REV D
Typical position of plates
1
2
3
4
5
RATING PLATE OF THE MACHINE
BEARING PLATE OF THE MACHINE
ADDITIONAL PLATE
MARKING PLATE FOR DIRECTION OF ROTATION
HANDLE OF WASTE GREASE EXHAUST VALVE
DIRECTION OF ROTATION SEEN FROM
THE DRIVE END TOWARDS THE MACHINE
CLOCKWISE COUNTER-CLOCKWISE REVERSING OPERATION
MACHINE ENDS:
D-END
N-END
= DRIVE END
= NON-DRIVE END
4
6
D-END N-END
5
3
2
5
1
4
D-END
N-END
5
1
2
3
