ABB AquaMaster 3 - Dimensions

AquaMaster 3
Electromagnetic flowmeter 2 Mechanical Installation
User Guide OI/FET2XX–EN Rev. E 11
2.3 Dimensions
2.3.1 AquaMaster 3
Dimensions in mm (in.)
Fig. 2.19 AquaMaster 3 Dimensions
Dimensions in mm (in.)
Fig. 2.20 AquaMaster 3 Battery Pack Dimensions
Ø 6.5
(0.25)
Ø13
(0.50)
115 (4.50)
177 (7.0)
50
(2.0)
185
(7.3)
28
(1.1)
136
(5.4)
Remote-mounted
Transmit te r
Sensor-mounted
Transmitte r
105
(4.1)
280 (11.0)
with
Connectors
125 (5.0)
135 (5.30)
70 (2.75)
135 (5.30)
8 (0.30)
