Electronic Commercial Water Meter
AquaMaster™ 3 Electrical Installation
18 IM/AM Issue 13
Fig. 3.9 Pipelines With Cathodic Protection, DN 40mm to 80mm
Caution. Do NOT ground Cathodically Protected Systems.
Insulating Sleeve
and Washer
(not supplied)
Insulated connecting wire
(not supplied). Must be
adequately rated to carry
cathodic currents.
Gasket
Bonding Cable
(supplied)
To Next Page
