26 AZ10 OXYGEN ANALYZER | COMBUSTION GAS ANALYSIS | OI/AZ10-EN REV. A
…8 Test gas connections
Schematic – AutoCal system
Figure 24 Schematic, AZ10 transmitter to AutoCal unit to probe


to test gas inlet at probe
14-core screened
AutoCal unit to


ABB 14-core cable/transmitter

Test gas 2
in
Cable
gland
Test gas 1
in
Test gas port
Mains
supply
Relays
Output
signals
AZ10 AutoCal
unit
AZ10 probe
AZ10 AutoCal
transmitter

