3 CONFIGURATION
3.2 Setting the Serial Transmission Parameters
Level d – Serial Communications Configuration
Note. To select this frame from anywhere in this page,
press the key for a few seconds.
Serial Configuration
0 OFF
1 2-wire connection, 2400 baud rate
2 4-wire connection, 2400 baud rate
3 2-wire connection, 9600 baud rate
4 4-wire connection, 9600 baud rate
5 2-wire connection, 19200 baud rate
6 4-wire connection, 19200 baud rate
Parity
None
Odd
Even
MODBUS address
[1 to 99]
Return to top of page.
SErL
LEVd
d.00
1
Addr
d.03
NONE
PrtY
d.02
0
S.CFG
d.01
To Next Page
