ABB ControlMaster CM10 Communications Supplement

ControlMaster CM10, CM15, CM30 and CM50
Universal process controllers and indicators,
1
/8,
1
/4 and
1
/2 DIN 5 MODBUS Communications
IM/CM/C–EN 19
5.8 Output Coils
46 Logic Equation 7 State
47 Logic Equation 8 State
48 Realtime Alarm 1 State
49 Realtime Alarm 2 State
50 Alarm 1 State
51 Alarm 1 Ack State
52 Alarm 2 State
53 Alarm 2 Ack State
54 Alarm 3 State
55 Alarm 3 Ack State
56 Alarm 4 State
57 Alarm 4 Ack State
58 Alarm 5 State
59 Alarm 5 Ack State
60 Alarm 6 State
61 Alarm 6 Ack State
62 Alarm 7 State
63 Alarm 7 Ack State
64 Alarm 8 State
65 Alarm 8 Ack State
66 Loop Break 1 State
MODBUS
Coil
Title
67 Loop Break 2 State
68 Delay Timer 1 State
69 Delay Timer 2 State
94 Loop 1 Autotune In Progress
95 Loop 2 Autotune In Progress
MODBUS
Coil
Title
0 Loop 1 Auto/Manual State
1 Loop 2 Auto/Manual State
2 Loop 1 Setpoint Mode
0 = Local, 1 = Remote
3 Loop 2 Setpoint Mode
0 = Local, 1 = Remote
4 Totalizer 1 Run State
5 Totalizer 2 Run State
6 Loop 1 Tracking State
7 Loop 2 Tracking State
MODBUS
Coil
Title
