ABB ControlMaster CM10 Communications Supplement

ControlMaster CM10, CM15, CM30 and CM50
Universal process controllers and indicators,
1
/8,
1
/4 and
1
/2 DIN 5 MODBUS Communications
20 IM/CM/C–EN
5.9 Input Registers
5.9.1 Read-only 32 Bits
5.9.2 Read-only Single Precision Float
MODBUS
Register
Title
4000 Totalizer 1 Batch Total
4002 Totalizer 2 Batch Total
4004 Totalizer 1 Secure Total
4006 Totalizer 2 Secure Total
MODBUS
Register
Title
5000 Analog I/P 1 Value
5002 Analog I/P 2 Value
5004 Analog I/P 3 Value
5006 Analog I/P 4 Value
5008 Loop 1 Process Variable
5010 Loop 2 Process Variable
5012 Loop 1 Control Output
5014 Loop 2 Control Output
5028 Loop 1 Deviation
5030 Loop 2 Deviation
5032 Loop 1 Feedforward Value
5034 Loop 2 Feedforward Value
5042 Loop 1 Actual Valve Position
5046 Loop 2 Actual Valve Position
5048 Loop 1 Actual Ratio
5050 Loop 2 Actual Ratio
5052 Loop 1 Remote Setpoint
5054 Loop 2 Remote Setpoint
5056 Loop 1 Split Output 1
5058 Loop 1 Split Output 2
5060 Loop 2 Split Output 1
5062 Loop 2 Split Output 2
5064 Process Variable 1 Max
5066 Process Variable 2 Max
5068 Process Variable 1 Min
5070 Process Variable 2 Min
5072 Process Variable 1 Ave
5074 Process Variable 2 Ave
5076 Volume 1
MODBUS
Register
Title
