ABB DCS550 Series User Manual

7
3ADW000395R0100 DCS550 Quick guide edisf a
73ADW000395R0100 DCS550 Quick guide edisf a
english
Brief instructions for CD and documents overview
We appreciate that you purchased an ABB DC drive power
converter and thank you for the trust you put in our products.
This brochure was put together to make sure that you con-
tinue to be satisfied with our product. It is intended to provide
you with a brief overview of the product's key data, EMC
notes, typical applications, start-up and trouble-shooting.
If you need more information about the product you are pro-
vided with a CD-ROM in addition to this brief documentation.
The CD-ROM is part of the delivery and features the following
contents:
Technical catalog (3ADW000378)
Comprehensive information to engineer complete DC drive
systems.
Manual (3ADW000379)
Detailed information, with all important particulars about the
individual components, like module dimensions, electronic
boards, fans and auxiliary components.
Information for mechanical and electrical installation are also
included.
Detailed information with all important issues about firmware
and setting of parameters. The manual includes information
for start-up and maintenance of the entire drive, in detailed
form.
This manual also includes Fault and Alarm codes and informa-
tion for trouble shooting.
Service Manual (3ADW000399)
for maintenance and repair of the converters.
Additional information about applications and technical
accessories (e.g. Hardware extension or Field bus interfaces)
are handled by separate manuals.
See table DCS550 manuals.
System requirements to use the CD-ROM
©
2
0
1
1
A
B
B
A
u
t
o
m
a
t
i
o
n
P
r
o
d
u
c
t
s
G
m
b
H
-
A
l
l
R
i
g
h
t
s
R
e
s
e
r
v
e
d
3ADW 000 377 R0201 / April 2011
System configuration
WINDOWS 98, NT, 2000, XP
Acrobat Reader 4.0 or higher
Internet Explorer 5.0 or higher
I
f
t
h
e
C
D
R
O
M
w
o
n
’
t
s
t
a
r
t
a
u
t
o
m
a
t
i
c
a
l
l
y
p
l
e
a
s
e
e
x
e
c
u
t
e
S
T
A
R
T
.
B
A
T
System confirmation
Win2000, WinXP
Before installation of PC tools
remove previous version by
CONTROL PANEL of your
PC
Read more details in
Quick Guide 3ADW000191
Content
This CD ROM provides
information about DCS550 and
contains PC tools:
DWL 2.93 for DC drives
+Commissioning Wizard 1.0
+DWL AP 2.2
FDT 2.2 Firmware
download kit
+ workspace
Firmware 1.1
DCS550
Ver.: 1.10
System confirmation
Win7, Win2000, WinXP
Before installation of PC tools
remove previous version by
CONTROL PANEL of your PC
− Operating system
WINDOWS 7, 2000, XP
− ACROBAT READER
In case the CD ROM does not
start automatically, please
double click on Setup.exe.
Further support
In addition we offer further support, since we can only be
satisfied when you, as our customer, are satisfied with us and
our products.
Internet
On the ABB homepage under
www.abb.com/dc
you'll find abundant information for
− DC products
− service support
− the latest updates
− tools
− downloads, etc.
Please don't hesitate to visit us.
Contacts
If you require any further information, please contact your
nearest ABB Drives office or send an email to:
DC-Drives@de.abb.com
Please give us your name, your company address and phone
number. We immediately put you in contact with our special-
ist.
