3ADW000395R0100 DCS550 Quick guide edisf a
713ADW000395R0100 DCS550 Quick guide edisf a
français
Type de convertisseur Taille Configuration Tension ventilateur
DCS550-S01-0020, ...,
DCS550-S02-0025
F1 - sans ventilateur
DCS550-S01-0045, ...,
DCS550-S02-0100
F1 1 1 x 3110KL-05W... (internal 24 V
DC
)
DCS550-S01-0135, ...,
DCS550-S02-0300
F2 2 2 x 4715MS (115 / 230 V
AC
)
DCS550-S01-0315, ...,
DCS550-S02-0450
F3 2 2 x 4715MS (115 / 230 V
AC
)
DCS550-S01-0470, ...,
DCS550-S02-0520
F3 3 2 x 4715MS (115 / 230 V
AC
)
2 x 3115FS (115 / 230 V
AC
)
DCS550-S01-0610, ...,
DCS550-S02-0820
F4 4 1 x W2E200 (230 V
AC
)
DCS550-S01-0900, ...,
DCS550-S02-1000
F4 4 1 x W2E250 (230 V
AC
)
Câblage du ventilateur
Type de ventilateur DCS550
Raccordement du ventilateur du DCS550
1 2 3 X52: 4 5
L N
230 V
AC
1 2 3 X52: 4 5
L N
115 V
AC
M
~
1 2 3
X52:
M
~
4 5
M55 M56
M
~
1 2 3
X52:
M
~
4 5
M55 M56
M
~
M
~
M57 M58
M55
M
~
1 2 3 4 5 X52:
L N
L N
1 2 3
X52:
4 5
L N
230 V
AC
1 2 3 X52: 4 5
L N
115 V
AC
ϑ
only 230 V
AC
M55
M
~
X19:
SDCS-PIN-F
Configuration 4
F4
Configuration 3
F3
Configuration 2
F2, F3
Configuration 1
F1
Terminals are located on top of the converter housing
Bornier sur le dessus du convertisseur
