ABB DPA UPScale ST120 - Connection of External Common Battery for DPA Upscale; Connection of External Separate Battery for DPA Upscale

Modifications reserved
Page 37/79
5.6.3 Connection of external separate battery for DPA UPScale
TM
External battery cabinet UPScale for
separate batteries per module
Frame : DPA UPSCALE ST S2 120
Fig 5.6.3-1: Connection of external separate batteries
5.6.4 Connection of external common battery for DPA UPScale
TM
External battery cabinet UPScale for
common batteries
Frame : DPA UPSCALE ST S2 120
Fig 5.6.4-1: Connection of external common batteries
PE
Battery
Fuses
for UPS
1
Battery
Fuses
for UPS
2
Battery
Fuses
for UPS
3
Battery
Fuses
for UPS
4
Battery
Fuses
for UPS
5
3 -
N
3 +
1 -
N
1 +
5 -
N
5 +
4 -
N
4 +
2 -
N
2 +
PE
3 -
2 -
1 -
5 -
4 -
N
N
N
N
N
3 +
2 +
1 +
5 +
4 +
Seperate Battery
