10/24-4.10 EN Rev. 9 EasyLine EL3000 Series Data Sheet 27
Dimensional drawings
Wall-mount housing (model EL3040)
366
420
360
480
Ø
Ø
20
404
360
315
11
23
³ 60
230
Clearance required to allow
the door to swing open
Dimensions in mm
