24 EasyLine EL3060 Series Commissioning Instructions
Pressure Sensor
Uras26
The pressure sensor is installed in the gas analyzer as standard. It is
optionally connected to a gas port via an FPM tube (flame barrier).
Magnos206
The pressure sensor is optionally installed in the gas analyzer. It is
optionally connected to a gas port via an FPM tube (flame barrier).
Caldos27
The pressure sensor is installed in the gas analyzer as standard. It is
optionally connected to a gas port via an FPM tube (flame barrier).
Caldos25
No pressure sensor is installed in the gas analyzer.
Information for the safe and correct operation of the pressure sensor
· If the pressure sensor (see page 24) is connected to the outside by
hose, the yellow plastic screw cap must be screwed out of the
connection fittings of the pressure sensor (flame barrier) before the
gas analyzer is commissioned.
· If the pressure sensor connection is not connected to the sample gas
outlet, an exact pressure correction is required so that the pressure
sensor and the sample gas outlet are on the same pressure level.
ATTENTION
The pressure sensor connection must not be connected to the sample
gas feed path for the measurement of flammable gases.
