Operating the Gas Analyzer 55
Overview of the functions
Function Instrument Configurator Modbus
Automatic calibration:
Start/cancel automatic calibration (also possible via digital
inputs)
X X
Activate/deactivate cyclically time-controlled automatic
calibration
X X X
Cycle time of the automatic calibration X
End-point calibration together with zero-point calibration X X
Date and time of the next automatic calibration (start of the
cycle)
X X
Test gas concentration X X X
Purging times X X
Output current response (for automatic and manual calibration) X
Calibration method (Magnos206) X X
Manual calibration:
Calibration method X X
Test gas concentration X X
Execute calibration X
Maintenance functions:
Calibration reset X
Calibration of the pressure sensor / Set atmospheric pressure
value
X
Measuring calibration cell (Uras26) X
Drift, delta drift (display) X X
Software version X X
Status information X X
Component parameters:
Range limits X X
Alarm value parameters X
Low pass time constant (T90 time, filter) X X
Active component X X X
Modbus parameters
4)
X
Profibus parameters
5)
X
Ethernet parameters X X
Signal inputs and outputs (I/O connections) X
4) For detailed Information on "Modbus", refer to the Technical Information "EL3000,
EL3060, EL3010-C – Modbus".
5) For detailed information on "Profibus", refer to the Technical Information "EL3000,
EL3060 – PROFIBUS DP/PA Interface".
