EN – Quick start-up guide 39
The first start is now complete and the drive is
ready for use.
Press (Done) to enter the Home view.
The Home view monitoring the values of the
selected signals is shown on the panel.
2 – Additional settings in the Primary settings menu
Make any additional adjustments, for example
macro, ramps and limits, starting from the Main
menu – press (Menu) to enter the Main
menu.
Select Primary settings and press
(Select)
(or ).
We recommend that you make at least these
additional settings:
• Choose a macro or set start, stop and reference
values individually
•Ramps
•Limits
With the Primary settings menu, you can also
adjust settings related to the motor, PID, fieldbus,
advanced functions and clock, region and display.
In addition, the menu contains an item to reset the
panel Home view.
To get more information on the Primary settings
menu items, press to open the help page.
