ABB FEW series User Manual

F, V, W S e r i e s
Electromagnetic flowmeters | Full-bore flow sensors 4 Specification
OI/FEF/FEV/FEW–EN Rev. D 19
WaterMaster optimized full-bore meter / full-bore meters flow performance (GPM)
Standard Calibration 0.4 % Class 2 High Accuracy Calibration 0.2 % Class 1
NPS/NB (DN) Q4 Q3 Q0.4% Q2 Q1 Q0.2% Q2 Q1
3
/8 (10) 13.8 11 0.73 0.06 0.035 1.38 0.09 0.053
1
/2 (15)34.727.71.850.140.093.480.220.14
3
/4 (20) 55 44 2.94 0.22 0.14 5.5 0.35 0.22
1 (25) 88 70.4 4.7 0.35 0.22 8.8 0.57 0.35
1
1
/4 (32) 137.6 110 7.3 0.57 0.35 13.2 0.88 0.57
1
1
/2 (40) 220 176 18.5 0.89 0.56 26.4 1.41 0.88
2 (50) 347 277 18.5 1.41 0.88 34.7 2.22 1.39
2
1
/2 (65) 550 440 29.4 2.24 1.40 55.0 3.52 2.20
3 (80) 881 704 47.0 3.58 2.24 70.4 5.64 3.52
4 (100) 1,376 1,101 73.4 5.59 3.49 110 8.81 5.50
5 (125) 1,376 1,101 73.4 5.59 3.49 110 8.81 5.50
6 (150) 3,467 2,774 185 14.1 8.81 277 22.2 13.9
8 (200) 5,504 4,403 294 22.4 14.0 440 35.2 22.0
10 (250) 8,806 7,045 470 35.8 22.4 704 56.4 35.2
12 (300) 13,759 11,007 734 55.9 34.9 1,101 88.1 55.0
14 (350) 22,014 17,611 1,174 89.5 55.9 1,761 141 88.1
16 (400) 22,014 17,611 1,174 89.5 55.9 1,761 141 88.1
18 (450) 34,673 27,738 1,849 141 88.1 2,774 222 139
20 (500) 34,673 27,738 1,849 141 88.1 2,774 222 139
24 (600) 55,036 44,029 2,935 224 140 4,403 352 220
27/28* (700) 88,057 70,446 7,045 451 282 7,045 704 440
29 (750) 88,057 70,446 7,045 451 282 7,045 704 440
30 (760) 88,057 70,446 7,045 451 282 7,045 704 440
32 (800) 88,057 70,446 7,045 451 282 7,045 704 440
36 (900) 137,590 110,072 11,007 704 440 11,007 1,100 688
39/40* (1000) 137,590 110,072 11,007 704 440 11,007 1,100 688
42 (1050) 137,590 110,072 11,007 704 440 11,007 1,100 688
44 (1100) 137,590 110,072 11,007 704 440 11,007 1,100 688
48 (1200) 220,143 176,115 17,611 1,127 704 17,611 1,761 1,101
52 (1350) 346,726 277,381 27,738 1,775 1,110 27,738 2,773 1,733
54 (1400) 346,726 277,381 27,738 1,775 1,110 27,738 2,773 1,733
60 (1500) 346,726 277,381 27,738 1,775 1,110 27,738 2,773 1,733
66 (1600) 346,726 277,381 27,738 1,775 1,110 27,738 2,773 1,733
68 (1650) 346,726 277,381 27,738 1,775 1,110 27,738 2,773 1,733
77 (1800) 550,358 440,287 44,029 2,818 1,761 44,029 4,403 2,752
77 (1950) 550,358 440,287 44,029 2,818 1,761 44,029 4,403 2,752
78 (2000) 550,358 440,287 44,029 2,818 1,761 44,029 4,403 2,752
78 (2000) 550,358 440,287 44,029 2,818 1,761 44,029 4,403 2,752
84 (2200) 880,573 704,459 70,446 4,509 2,818 70,446 7,045 4,403
96 (2400) 880,573 704,459 70,446 4,509 2,818 70,446 7,045 4,403
*Size is dependent on flange specification
