FSM4000 ELECTROMAGNETIC FLOWMETER | DS/FSM4000-EN REV. L
—
Model SE41F
Specifications
Temperature graph
1
Ambient temperature °C
2
Measuring medium
temperature °C
3
Standard flange (steel):
Hard/soft rubber max. 90/60
°C (194 to 140 °F)
4
Stainless steel flange
5
Standard flange (steel): PTFE /
PFA / ETFE max. 130 °C (266 °F)
6
High temperature: thick PTFE /
PFA max. 180 °C (356 °F)
Figure 14: Measuring medium temperature dependent on the ambient temperature
Max. permissible cleaning temperature
PTFE-, PFA-design
CIP cleaning
Liner
Flowmeter
sensor
T
max
t
max
Min
T
amb.
Steam cleaning
PTFE, PFA
150 °C (302 °F)
60
25 °C (77 °F)
Wet cleaning
PTFE, PFA
140 °C (284 °F)
60
25 °C (77 °F)
If the ambient temperature is > 25 °C, the difference must be
subtracted from the max. cleaning temperature.
T
max - ∆ °C.∆ °C = (Tamb. - 25 °C)
Weight
Refer to Dimensions on page 31.
Min. permissible pressure as a function of measuring
medium temperature
Liner
Nominal diameter
DN
P
Operation
mbar abs
at
T
Operation
Hard rubber
15
to 1000
(1/2 to 40″)
0
< 90 °C (194 °F)
Soft rubber
50
to 1000
(2
to 40″)
0
< 60 °C (140 °F)
PTFE
10
to 600
(3/8
to 24″)
270
400
500
< 20 °C (68 °F)
< 100 °C
(212 °F)
< 130°C (266 °F)
Thick PTFE
high
temperature
design
25
to 80 (1 to 3″)
100
to 250 (4 to 10″)
300 (12″)
0
67
27
< 180 °C (356 °F)
< 180 °C (356 °F)
< 180 °C (356 °F)
PFA
3
to 200
(1/10 to 8″)
0
0
< 130°C (266 °F)
< 180 °C (356 °F)
ETFE
25 to 1000 (1 to 40″)
100
< 130°C (266 °F)
Ceramic
carbide
25
to 1000
(1 to 40″)
0
< 80 °C (176 °F)
Sensor material
Parts
Standard
Others
Liner
PTFE, PFA, hard rubber, soft
rubber, ETFE
Ceramic carbide
Signal and ground
electrode for
•
Hard rubber
•
Soft rubber
Stainless steel 1.4571 (316 Ti)
Hastelloy B
-3
(2.4600), Hastelloy C
-
4 (2.4610), titanium,
tantalum, platinum
-
iridium, stainless
steel 1.4539 (904 L)
•
PTFE, PFA, ETFE
Hastelloy C
-4 (2.4610)
Stainless steel 1.4571
(316
Ti), Hastelloy B-
3
(2.4600), titanium,
tantalum, platinum
-
iridium, stainless
steel 1.4539 (904 L)
Grounding plate
Stainless steel 1.4571 (316 Ti)
On request
Protection plate
Stainless steel 1.4571 (316 Ti)
On request
