ABB HT613213 - Tools; Table 71: Customer Tool Set 90009

Operation Manual / A170-M.. - A175-M..
14 Tools / 
© Copyright 2022 ABB. All rights reserved. HZTL4033_EN Rev.K January 2022
14 Tools
For the work described in the Operation Manual, the customer tool set 90009 is required.
90009 Designation Quantity
90010 Wooden crate 1
90025 Support angle complete 1
90190 Lifting device 1
90192 Fixing segment 1
90196 Hexagon-head screw 2
90197 Hexagon-head screw 2
90198 Washer 2
90199
1)
Adapter 1
90195 Shackle 2
90321 Guide stud 2
90328 Guide plate bolt 3
90336 Guide stud 1
90338 Mounting plate 1
90339 Socket screw 2
90441 Lifting spigot 1
90450 Support 2
90490 Guide stud 2
90802 Guide stud 3
90900 Press-off screw 6
90901
2)
Press-off screw 5
90915 Press-off screw 3
90916
1)
Press-off screw 5
90917 Press-off screw 1
94003 Locking device 1
94006 Hexagon-head screw 10
94007 Hexagon-head screw 12
Table71: Customer tool set 90009
1) Only for A170-M
2) Only for A175-M
This tool set can be ordered from any ABB Turbocharging Service Station. The following spe-
cifications must be included in the order:
¡ Turbocharger type
¡ Designation and part number of the tool set.
