Operation Manual / A170-M.. - A175-M..
9 Disassembly and assembly / 9.1 Introduction
© Copyright 2022 ABB. All rights reserved. HZTL4033_EN Rev.K January 2022
Tightening torques for assembly devices
Unless otherwise described, the screws and nuts of the assembly devices supplied by ABB
must be tightened in such a way that they are tight-fitting.
WARNING
Suspended loads
Loads that are not attached according to regulations can cause injury to
personnel or fatal accidents.
u Only fasten the turbocharger, assemblies or individual parts on properly
functional lifting gear with sufficient load limit.
u Pay attention to the correct attachment of loads on the crane hook.
u People must not stand beneath suspended loads.
Wear safety gloves to protect against mechanical hazards.
Wear safety helmet.
Definition of terms
¡ Suspension point
Defined loading point on a component or an assembly (blind hole thread, eyelet, lug).
¡ Assembly device
Devices that are fitted on the turbocharger in order to obtain a suspension point. As-
sembly devices are specially constructed and designed for the defined use; they are not
commercially available products. Use assembly devices only for the described applica-
tions.
¡ Lifting gear
Equipment for the lifting and transporting of loads (ropes, chain block, crane). Lifting
gear is not supplied by ABB.
Page 77 / 146
