range is used to set the range of the measurement associated with the transmission
output.
Only when the association type is active power, reactive power, power factor, or
frequency, the direction can be set to Bidirectional. 4mA represents 0 and 20mA
represents full scale when set to unidirectional. When set to Bidirectional, 4mA
represents the reverse range, 20mA represents the forward range.
Example 1: When the range is set to 1.000kW, if set to unidirectional, the output
of 4mA represents 0kW, the output of 20mA represents 1.000kW, the output of 12mA
represents 0.500kW; if set to bidirectional, the output of 4mA represents -1.000kW,
20mA represents 1.000 kW, 12mA represents 0kW.
Example 2: If the frequency F is set to Bidirectional, real-scale range is 50Hz ±
range, and 12mA represents 50Hz.
Association type is used to select energy which is associated to transmission
output
Association
Type
Description
Remark
Associatio
n Type
Description
Remark
1
Related Uab
Unidirectional
16
Related P
Unidirectional /
Bidirectional
2
Related Ubc
Unidirectional
17
Related Q
Unidirectional /
Bidirectional
3
Related Uca
Unidirectional
18
Related S
Unidirectional
4
Related average of
line voltage
Unidirectional
19
Related PFa
Unidirectional /
Bidirectional
5
Related Uan
Unidirectional
20
Related PFb
Unidirectional /
Bidirectional
6
Related Ubn
Unidirectional
21
Related PFc
Unidirectional /
Bidirectional
7
Related Ucn
Unidirectional
22
Related Pa
Unidirectional /
Bidirectional
8
Related average of
phase voltage
Unidirectional
23
Related Pb
Unidirectional /
Bidirectional
9
Related Ia
Unidirectional
24
Related Pc
Unidirectional /
Bidirectional
10
Related Ib
Unidirectional
25
Related Qa
Unidirectional /
Bidirectional
11
Related Ic
Unidirectional
26
Related Qb
Unidirectional /
Bidirectional
12
Related average of
current
Unidirectional
27
Related Qc
Unidirectional /
Bidirectional
13
Related In
Unidirectional
28
Related Sa
Unidirectional
14
Related F
Unidirectional /
Bidirectional ，
Bidirectional
29
Related Sb
Unidirectional
