4.3.2 Switch actuator settings
Fig.
5
: Switch actuator settings
No.
Functions
1
Existing switch actuator list: Press button √ to modify the settings.
2
Add a new actuator list:Totally, up to 10 switch actuator lists can be added.
3
Enter to change target address with “+” or “-” button from 001 to 199.
4
Rename the switch actuator list:
Scroll through letters of the alphabet or numbers one by one with “+” or
“-” button
3
4
SWITCH ACTUATOR
Actuator 1
(001)
Add New
Target Address
Rename
002
light
Save
Cancel
SWITCH ACTUATOR
2
1
Add a new list
