ABB MNS-SG - Section Weight

20 MNS-SG Operation and Maintenance | Manual
3.2. Section weight
Some heavy devices or sensitive parts may be shipped
separately. Weights listed in the following table are
approximate. Consult equipment shipping documents for
actual weights and dimensions.
NOTE: Breaker compartment and breakers weight shall be multiplied times the quantity in each section
*For transition section only
NOTE: Hardware and control factor adds 4% to total
Width
Units
Enclosure
and structure
Copper busbars
Depth
1600
2000
3200
4000
5000
1852 mm
(72.9 in)
2000 mm
(80.7 in)
3P-3W
3P-4W
3P-3W
3P-4W
3P-3W
3P-4W
3P-3W
3P-4W
3P-3W
3P-4W
500 mm*
(19.6 in)
kg
269.9
283.3
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
lbs
595.0
624.6
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
600
(23.6 in)
kg
326.0
339.9
174.1
183.0
222.8
233.9
N/A
N/A
N/A
N/A
N/A
N/A
lbs
718.6
749.4
383.8
403.4
491.2
515.7
N/A
N/A
N/A
N/A
N/A
N/A
700
(27.5 in)
kg
345.5
360.2
182.0
191.9
230.8
243.4
N/A
N/A
N/A
N/A
N/A
N/A
lbs
761.7
794.0
401.1
423.1
508.8
536.6
N/A
N/A
N/A
N/A
N/A
N/A
800
(31.5 in)
kg
374.8
390.1
N/A
N/A
N/A
N/A
412.6
434.2
N/A
N/A
N/A
N/A
lbs
826.3
860.0
N/A
N/A
N/A
N/A
909.6
957.2
N/A
N/A
N/A
N/A
1000
(39.4 in)
kg
413.1
429.7
N/A
N/A
N/A
N/A
N/A
N/A
615.8
649.2
810.6
850.6
lbs
910.7
947.2
N/A
N/A
N/A
N/A
N/A
N/A
1357.6
1431.2
1787.1
1875.3
Accessories
Overhead lifting device
118 lbs
54 kg
CTs (set of three up to 3200A)
33 lbs
15 kg
CTs (set of three, 4000A)
77 lbs
35 kg
HRG
132 lbs
60 kg
PTs (each)
11 lbs
5 kg
Close coupling or bus duct raisers (3200A)
441 lbs
200 kg
Close coupling or bus duct raisers (5000A)
661 lbs
300 kg
Breaker/instrument/empty
compartment
63.1 lbs (28.6 kg)
73.3 lbs (33.25 kg)
83.8 lbs (38 kg)
94.1 lbs (42.7 kg)
114.6 lbs (52 kg)
Breaker/cradle
E2.2
E4.2 (up to 2500A)
E4.2 (3200A)
E6.2
128 lbs
58 kg
261 lbs
118 kg
300 lbs
136 kg
486 lbs
220 kg
